MOOG eksplosjonssikre børsteløse servomotorer

MOOG servmotorer
  • Certified to comply with the Essential Health and Safety Requirements relating to the design and construction of equipment and protective systems intended for use in potentially explosive environments.
  • ATEX and IECEx certified
  • AC Servo Motor (Synchronous)
  • Low Inertia
  • Natural Cooling
  • Compact, lightweight
  • Proprietary low cogging design
  • Rugged, minimum maintenance
  • Flexible design

Kontakt Hydex vedrørende MOOG eksplosjonssikre børsteløse servomotorer

Type    Explosion Brushless Servo Motor
Stall torque 0.52-66.72 Nm
Maximum torque 1.6-239.34 Nm
Rated speed 2000-7800 r/min
Rotor inertia 0.16-151.08 kg cm²
Square flange 70-190 mm
Approvals available
Typical applications Oil and Gas Exploration
Power Generation
Mining
Industrial production machinery with environments where vapors or gasses form flammable or explosive ambients may be present
For mer informasjon Klikk her --- Katalog --- Oversikt

Kontakt Hydex vedrørende MOOG eksplosjonssikre børsteløse servomotorer
