Certified to comply with the Essential Health and Safety Requirements relating to the design and construction of equipment and protective systems intended for use in potentially explosive environments.
ATEX and IECEx certified
AC Servo Motor (Synchronous)
Low Inertia
Natural Cooling
Compact, lightweight
Proprietary low cogging design
Rugged, minimum maintenance
Flexible design

Type		Explosion Brushless Servo Motor
Stall torque		0.52-66.72 Nm
Maximum torque		1.6-239.34 Nm
Rated speed		2000-7800 r/min
Rotor inertia		0.16-151.08 kg cm²
Square flange		70-190 mm
Approvals available
Typical applications		Oil and Gas Exploration Power Generation Mining Industrial production machinery with environments where vapors or gasses form flammable or explosive ambients may be present
