W.E.ST. DSG-111P digital command signal module

W.E.ST. forsterkere for proporsjonalventiler
  • 16 selectable demand values
  • Four quadrant ramps or 16 selectable ramp times
  • Analogue input and demand values are combinable with following functions: +, -, *, /, min, max
  • Analogue signal monitoring with definable area
  • Deadband compensation
  • Parameter for valve adaptation (MIN, MAX, POL)
  • Failure monitoring '
  • Simple and application orientated parametering
  • Adjustments via RS232C interface

Kontakt Hydex vedrørende W.E.ST. DSG-111P digital command signal module

Type    Digital command signal module
Use Hydraulic proportional valves
Power supply 12… 30 VDC (incl. ripple)
Current consumption <100 mA
External fuse 1 A (medium lag)
Interface RS 232C, 9600 Baud, 1 stop bit, No parity, Echo Mode
Housing Snap-On Module EN 50022
Polyamide PA 6.6
Combustibility class V0 (UL94)
Protection class IP20
Temperature range -20°C to +60°C
Humidity <90% (not condensing)
Connectors RS232: 3,5mm JISC-6560
4 x 4pol. screw terminals
PE: direct via DIN rail
For mer informasjon Klikk her --- Datablad --- Appendix
